3D Adjustment Three-Section Force Small Angle Soft-closing Hinge
Item No. 8022061
Cabinet Hinges
Print
Overlay:
Base Plate Height / Holes:
Hole Distance:
Head Cup Size:
Opening Angle:
Surface Treatment:
|
Item No.
|
Overlay
|
Base Plate Height / Holes
|
Hole Distance
|
Head Cup Size
|
Opening Angle
|
Surface Treatment
|
| 8022061 | Full overlay | H=0, 3 holes | 1-7/8"(48mm) | Ф1-3/8"x7/16"(Ф35x11.5mm) | 105° | Nickel plating |
| 8022062 | Half overlay | H=0, 3 holes | 1-7/8"(48mm) | Ф1-3/8"x7/16"(Ф35x11.5mm) | 105° | Nickel plating |
| 8022063 | Inserted | H=0, 3 holes | 1-7/8"(48mm) | Ф1-3/8"x7/16"(Ф35x11.5mm) | 105° | Nickel plating |
View More
Pack Up
Prodcut Description
● Snap-on installation
● Fast mounted
● 7/16" (11.5mm) cup depth
● 50,000 opening and closing cycles
● Neutral Salt Spray Test for 48 Hours
● Vertical Adjustment ±1/16" (1.5mm), Cover Position Adjustment ±3/32" (2mm), Door Gap Adjustment ±3/32" (2mm)
● Suitable for door thickness: 9/16"~7/8" (14~22mm)
Product Size
