Trinodal Ball Bearing Slide
Item No. 7043302
Sign in to view prices
Drawer Slides
Print
Item No.
Nominal Length
Extension Length
Material Thickness
7043302 11-13/16" (300mm) 11-15/16" (303mm) Outer/Miidle/Inner: 1/32" (1.0mm) *1/32" (1.0mm) *1/16" (1.2mm)
7043352 13-25/32" (350mm) 15-9/32" (388mm) Outer/Miidle/Inner: 1/32" (1.0mm) *1/32" (1.0mm) *1/16" (1.2mm)
7043402 15-3/4" (400mm) 15-7/8" (403mm) Outer/Miidle/Inner: 1/32" (1.0mm) *1/32" (1.0mm) *1/16" (1.2mm)
7043452 17-23/32" (450mm) 19-1/32" (483mm) Outer/Miidle/Inner: 1/32" (1.0mm) *1/32" (1.0mm) *1/16" (1.2mm)
7043502 19-11/16" (500mm) 19-7/8" (505mm) Outer/Miidle/Inner: 1/32" (1.0mm) *1/32" (1.0mm) *1/16" (1.2mm)
7044252 9-27/32" (250mm) 9-17/32" (242mm) Outer/Miidle/Inner: 1/32" (0.8mm) *1/32" (0.8mm) *1/32" (1.0mm)
7044302 11-13/16" (300mm) 11-15/16" (303mm) Outer/Miidle/Inner: 1/32" (0.8mm) *1/32" (0.8mm) *1/32" (1.0mm)
7044352 13-25/32" (350mm) 15-9/32" (388mm) Outer/Miidle/Inner: 1/32" (0.8mm) *1/32" (0.8mm) *1/32" (1.0mm)
7044402 15-3/4" (400mm) 15-7/8" (403mm) Outer/Miidle/Inner: 1/32" (0.8mm) *1/32" (0.8mm) *1/32" (1.0mm)
7044452 17-23/32" (450mm) 19-1/32" (483mm) Outer/Miidle/Inner: 1/32" (0.8mm) *1/32" (0.8mm) *1/32" (1.0mm)
7044502 21-21/32" (550mm) 19-7/8" (505mm) Outer/Miidle/Inner: 1/32" (0.8mm) *1/32" (0.8mm) *1/32" (1.0mm)
7043252 9-27/32" (250mm) 9-17/32" (242mm) Outer/Miidle/Inner: 1/32" (1.0mm) *1/32" (1.0mm) *1/16" (1.2mm)
View More
Pack Up
Prodcut Description

BULLET POINT:

● Touch-activated Ejection, Efficient and Smooth: Utilizing the mechanism,  the touch-activated design enables efficient and smooth ejection, free   from lag or resistance.

● T-shaped Head Design, Excellent Ejection Effect: Effectively prevents the   drawer from jumping out.  ●Snap-on Design, Easy to Remove and Adjust: When the slide rail installation  position is restricted by the cabinet and must be deeply embedded (within   10mm), or when improper installation causes the slide rail to extend too far   into the cabinet resulting in buffer hook failure, this design allows for easy   self-recovery to restore the buffering effect.

Product Size

Trinodal Ball Bearing Slide3.png
