悦动三节反弹钢珠滑轨
成21-11-0811-14
悦动三节反弹钢珠滑轨
成21-11-0811-14
Trinodal Ball Bearing Push-Open Slide
Item No. 7045252
Sign in to view prices
Drawer Slides
Print
Item No.
Description
Nominal Length
Extension Length
Material Thickness
7045252 Youth trinodal ball bearing push-open slide (black) 9-27/32" (250mm) 7-11/16" (195mm) Outer/Miidle/Inner: 1/32" (1.0mm) *1/32" (1.0mm) *1/16" (1.2mm)
7045302 Youth trinodal ball bearing push-open slide (black) 11-13/16" (300mm) 11-1/32" (280mm) Outer/Miidle/Inner: 1/32" (1.0mm) *1/32" (1.0mm) *1/16" (1.2mm)
7045352 Youth trinodal ball bearing push-open slide (black) 13-25/32" (350mm) 13-25/32" (350mm) Outer/Miidle/Inner: 1/32" (1.0mm) *1/32" (1.0mm) *1/16" (1.2mm)
7045402 Youth trinodal ball bearing push-open slide (black) 15-3/4" (400mm) 15-3/4" (400mm) Outer/Miidle/Inner: 1/32" (1.0mm) *1/32" (1.0mm) *1/16" (1.2mm)
7045452 Youth trinodal ball bearing push-open slide (black) 17-23/32" (450mm) 17-23/32" (450mm) Outer/Miidle/Inner: 1/32" (1.0mm) *1/32" (1.0mm) *1/16" (1.2mm)
7045502 Youth trinodal ball bearing push-open slide (black) 19-11/16" (500mm) 19-11/16" (500mm) Outer/Miidle/Inner: 1/32" (1.0mm) *1/32" (1.0mm) *1/16" (1.2mm)
View More
Pack Up
Prodcut Description
BULLET POINT:

● Double Spring and Center Pipe Combination Design

● Touch-activated Ejection, Efficient and Smooth

● T-shaped Head Design, Excellent Ejection Effect

● Cushion Touch Positioning Adopts Large-width Angle Design

● Snap-on Design, Easy to Remove and Adjust

● Buffer Bottom Clearance Design, More Stable Installation

Product Size

Trinodal Ball Bearing Push-Open Slide1.png

Trinodal Ball Bearing Push-Open Slide2.png
